Quad-radio, 802.11ac Wave 2 access point with a powerful beamforming antenna designed to support large venues and high-density networks.

The WiFi BaseStation XG (UWB XG) is a high-capacity, 802.11ac Wave 2 access point with (4) 5 GHz (4x4 MU-MIMO) radios, including (3) client-dedicated ones and (1) for persistent internet threat management. The powerful UWB XG can reach a 5.2 Gbps aggregate throughput rate and supports up to 1,500 clients. This access point is powered by 802.3bt PoE++ and features (1) GbE RJ45 port and (1) 10GbE ICM Ethernet port to facilitate a range of connections. The UWB XG can be set up in minutes and fully managed with the UniFi Network web application or mobile app.

Features:

• (4) 5 GHz (4x4 MU-MIMO) radios [(3) 802.11ac Wave 2 radios for clients, (1) for network security]
• 5.2 Gbps aggregate throughput rate over the 5 GHz band
• 1,500-client limit
• Beamforming antenna
• Powered by 802.3bt PoE++ (PoE injector included)
• (1) GbE RJ45 port
• (1) 10GbE ICM Ethernet port

Datasheet

Managed with the UniFi Network application.
